Object 3D Snap

Object 3D Snap

Menu: Tools Drafting settings > Tab Object 3D snap
Status bar:
Hotkey: F4
Command line: DDRMODES, DSETTINGS, SE
Allows you to make a snap to location points of 3D Solids and shapes recognized in the point cloud by shaoe recognition commands.

Modes of object 3D snap:

Edge Node	Snap to the nearest vertex of a 3D object or to a control vertex on a spline created with control vertices.
Midpoint	Snap to the midpoint of a face edge.
Shape Center	Snap to a face center.
Node	Snap to a node on a spline created with fit points.
Normal	Snap to a point normal to a face.
Nearest to Plane	Snap to the point closest to the face of the 3D object.

Snap to point clouds

For the possibility to snap to location points of geometric shapes recognized in a cloud, the snap to features mode should be enabled:
Ribbon: Point Clouds > Settings > Snap to edges and nodes
Menu: Point Clouds – Settings > Snap to Edges and Nodes
Command line: SWITCHPCSNAPFEATURES
